Rebar & Wire Rod Descaling Machine | Coil Steel Shot Blasting Production Line
In-line scale removal for rebar, wire coils a…
Request a quoteStruggling with scale removal on coiled steel bars before drawing or cold heading? This through-feed wire rod blaster operates in-line with rolling mills, removing rust at high speeds without twisting the coils. It improves die life and surface quality of finished fasteners. It is suitable for rebar, wire coils, and round bars. Automatic coil loading and unloading options are available.
Model Comparison
Compare available models and technical parameters.
| Parameter | High-Speed Steel Bar / Wire Shot Line |
|---|---|
| Wire diameter | Φ4–Φ16 mm |
| Feed speed | ≤60 m/min; synchronized with drawing or take-up machine |
| Blast wheel capacity | 4×280 kg/min |
| Blast wheel power | 4×22 kW, variable frequency |
| Elevator capacity | 90 t/h |
| Elevator power | 4 kW |
| Separator capacity | 45 t/h |
| Separator air speed | 4–5 m/s |
| Steel shot diameter | Φ0.2–Φ0.3 mm |
| Steel shot material | High-carbon steel shot |
| Initial abrasive load | Approx. 3200 kg |
| Dust collector air volume | 5000 m³/h |
| Dust collector power | 3 kW |
